Feature Descriptions MDM6000 Satellite Modem
14.9 Device Redundancy
Redundancy is very important as a single failure of the modulator affects many services at the same
time.
Reliable operation of the satellite modulation in a satellite network is of key importance. The
MDM6000 works seamlessly together with the Newtec AZ202/AZ212 redundancy switches to
provide best-in-class system uptime.
Refer to the user manual of the USS0202/USS0212 Universal Switching System.
The following figures shows a 1+1 protection scheme built up with the AZ202 switch, one in normal
operation and one in redundant operation.
Normal Operation
Redundant Operation
