Data Interfaces MDM6000 Satellite Modem
• Enable;
Destinations:
• Demod Id (read only);
• Enable: enable or disable the BBF over IP out to the specified destination IP Address (with
corresponding UDP port);
• Destination IP Address;
• Destination UDP Port.
Monitoring
Monitoring is performed on this interface to get an overview on the outgoing BBF Bit Rate and of the
BBF frame count.
Parameter Description
Output BBF Bit Rate Displays the outgoing bit rate in Mbps;
BBF In Count Displays the amount of frames that are inserted by the
demodulator.
BBF Out Count Displays the amount of frames that are sent towards the
receiving device.
BBF Drop Count Displays the amount of frames that are dropped
