How to Manage the Device MDM6000 Satellite Modem
Pane
No.
Pane name Function
2 Alarms list
pane
The alarm list displays the alarms generated by the device.
Alarms are sorted first by their activity and then by their severity
(from critical alarms to warnings).
• It is possible to filter Active, Memorized or All Alarms;
• Clear the memorized alarms counter;
• View details of the generated alarm. (State, History)
3 Function
controls pane
This pane displays by default the overview tab.
This overview tab provides:
• An overview of the signal flow in the device;
• Basic settings used to perform a configuration;
• By clicking on the icon in the right upper corner of the
functional block, a detailed overview with all parameters of the
functional block opens in a new tab.
4 Status bar The status bar informs on:
• On-going interaction with the device via the status field on the
left.
• Refresh button, the status of the device gets refreshed;
Click the arrow to configure the time interval of refreshing the
status of the device.
5 Tasks pane The tasks pane provides an overview of different tasks that are
possible on following levels:
• Device;
– Configurations
– Reset.
• ACM Controller;
– Margin Settings
• Logs;
– Device Logging
– ACM Logging
– AUPC Logging
• Documentation.
– Download the Reference Manual
– Download the SNMP MIBs
• Toolbox;
– Diagnostics Report
• Maintenance;
– Software Upgrade
– License Upgrade
• Equalink™;
– Automated Linear
– Automated Non-Linear
– Manual Import
– Reset Predistortion
