How to Manage the Device MDM6000 Satellite Modem
Dialogue box
Type
Example
Data field
Check box The check box has two states.
Off
On
Table
Functional group This groups a set of parameters that belong together. The following
figure is an example of specific DVB-S2 settings (Note, this group can be
found under the modulator.)
Reset button
Open Detailed
View
Click this icon to open the detailed view, zooming in on the parameters
of the specific block.
Delete
Click this icon to delete a connection.
Hovering over a parameter shows more details about it.
