4-34
4-2 Function Mode
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
4
Parameter List
I/O terminal function
C160
Input Terminal
1 Response
Time
0. to 200. (× 2 ms)
1. no yes
ms 5-32
C161
Input Terminal
2 Response
Time
1. no yes
C162
Input Terminal
3 Response
Time
1. no yes
C163
Input Terminal
4 Response
Time
1. no yes
C164
Input Terminal
5 Response
Time
1. no yes
C165
Input Terminal
6 Response
Time
1. no yes
C166
Input Terminal
7 Response
Time
1. no yes
C169
Multi-step
Speed/Position
Determination
Time
0. to 200. (× 10 ms) 0. no yes ms 5-63
Control parameter
H001
Auto-tuning
Selection
00: Disabled
01: Enabled (motor does not
rotate)
02: Enabled (motor rotates)
00 no no − 5-146
H002
Motor
Parameter 1
00: Standard motor parameter
01: Auto-tuning parameter
00 no no
−
5-145
H202
Motor
Parameter 2
00 no no
H003
Motor Capacity 1
0.1/0.2/0.4/0.55/0.75/1.1/1.5/
2.2/3.0/3.7/4.0/5.5/7.5/11.0/
15.0/18.5
Default
setting
no no kW
H203
Motor Capacity 2
Default
setting
no no kW
H004
Motor Pole
Number 1
2/4/6/8/10
4nono
pole
H204
Motor Pole
Number 2
4nono
H005
Speed
Response 1
1. to 1000.
100. yes yes
−
H205
Speed
Response 2
100. yes yes
Parameter No. Function name Monitor or data range
Default
setting
Set data
Data can
be set
during
RUN
Data can be
changed
during RUN
Unit Page
