Omron SYSDRIVE MX2 SERIES User Manual

5-2
5-1 Monitor Mode
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
Rotation Direction Monitor [d003]
Displays the rotation direction of the Inverter.
The RUN LED indicator is lit during forward/reverse rotation.
In general, the forward direction of the motor is the counterclockwise direction as viewed from
the axial direction.
PID Feedback Value Monitor [d004]
When "01: Enabled" or "02: Reverse output enabled" is selected in PID Selection (A071), the
PID feedback value can be monitored.
Also, conversion is possible using PID Scale (A075).
"d004 display" = "Feedback value [%]" × PID Scale (A075)
Parameter
No.
Function name Data
Default
setting
Unit
d003
Rotation Direction
Monitor
F: Forward
−−o: Stop
r: Reverse
Forward
Parameter
No.
Function name Data
Default
setting
Unit
d004
PID Feedback
Value Monitor
0.00 to 99.99 (Displayed in increments of
0.01.)
−−
100.0 to 999.9 (Displayed in increments
of 0.1.)
1,000. to 9,999. (Displayed in increments
of 1.)
1,000 to 9,999 (Displayed in increments
of 10.)
⎡100 to ⎡999 (Displayed in increments of
1,000.)
A075 PID Scale
0.01 to 99.99 (Displayed in increments of
0.01.)
1.00 Time
Related functions A071, A075
