5-9 Functions Relating to Protections, Warnings and Various Output Signals
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
Thermal Warning
This function outputs an alarm signal before electronic thermal overload protection is activated.
The warning level can be set in C061.
Allocate "13: THM" to any Multi-function Output Terminal Selections (C021 to C022) or Multi-
function Relay Output Function Selection (C026).
Parameter
No.
Function name Data
Default
setting
Unit
C061
Electronic
Thermal Warning
Level
0.
The Inverter does not operate.
90. %
1. to 100.
*1
Set a thermal warning signal output
level.
C021 to C022
C026
Multi-function
Output Terminal
Selection
Multi-function
Relay Output
Function Selection
13: THM (Thermal warning) −−
*1.Set a percentage relative to the electronic thermal multiplication value. When the value reaches 100%,
Overload Trip (E05) occurs.
