Checking Before Unpacking
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
Checking Before Unpacking
Checking the Product
On delivery, be sure to check that the delivered product is the Inverter 3G3MX2 model that you
ordered.
Should you find any problems with the product, immediately contact your nearest local sales
representative or OMRON sales office.
Checking the Nameplate
Checking the Model
Checking the Accessories
Note that Instruction manual is the only accessory included with the 3G3MX2 model.
Mounting screws and other necessary parts must be provided by the user.
Inverter model
Input specifications
Output specifications
3G3MX2-A2055
Maximum applicable motor capacity (CT rating)
004
007
015
022
0.4 kW
0.75 kW
1.5 kW
2.2 kW
5.5 kW
7.5 kW
11 kW
15 kW
Voltage class
B
2
4
1-phase 200 V AC (200 V class)
3-phase 200 V AC (200 V class)
3-phase 400 V AC (400 V class)
Enclosure rating
A
Panel-mounting (IP10 min.) or closed
wall-mounting models
0.1 kW
0.2 kW
001
3.0 kW
3.7 kW
4.0 kW
030
037
040
002
055
075
110
150
