5-1 Monitor Mode
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
Torque Bias Monitor [d010]
During sensorless vector control, the currently set torque bias amount is displayed.
Output Torque Monitor [d012]
Displays an estimated value of the Inverter's output torque.
Note: The power running direction is positive and regeneration direction is negative during forward
rotation, while the power running direction is negative and regeneration direction is positive during
reverse rotation.
 This display is shown only when the sensorless vector control is selected. If any other control
mode is selected, the correct value is not displayed.
Output Voltage Monitor [d013]
Displays the output voltage of the Inverter.
 Set Motor Incoming Voltage Selection (A082/A282) correctly. The correct value may not be
displayed.
Parameter
No.
Function name Data
Default
setting
Unit
d010 Torque Bias Monitor −200. to 200. − %
Related functions A044, P036, P037, P038
Parameter
No.
Function name Data
Default
setting
Unit
d012
Output Torque
Monitor
−200. to 200.
− %
Related functions A044/A244
Parameter
No.
Function name Data
Default
setting
Unit
d013
Output Voltage
Monitor
0.0 to 600.0
− V
