Omron SYSDRIVE MX2 SERIES - Standard Specification List

9-1
9-1 Standard Specification List
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
9
Specifications
9-1 Standard Specification List
Data of standard motors are shown. Take note that the actual torque characteristics vary
depending on the motor used.
Three-phase 200 V Class
CT: Heavy load, VT: Light load
Function name 3-phase 200 V
Model name
(3G3MX2-)
A2001 A2002 A2004 A2007 A2015 A2022 A2037 A2055 A2075 A2110 A2150
Applicable
motor
capacity
kW CT 0.1 0.2 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15
VT 0.2 0.4 0.75 1.1 2.2 3.0 5.5 7.5 11 15 18.5
HP
CT 1/8 1/4 1/2 1 2 3 5 7 1/2 10 15 20
VT 1/41/2 11 1/23 47 1/210 15 20 25
Rated
output
capacity
[kVA]
200 V CT 0.2 0.5 1.0 1.7 2.7 3.8 6.0 8.6 11.4 16.2 20.7
VT 0.4 0.6 1.2 2.0 3.3 4.1 6.7 10.3 13.8 19.3 23.9
240 V CT 0.3 0.6 1.2 2.0 3.3 4.5 7.2 10.3 13.7 19.5 24.9
VT 0.4 0.7 1.4 2.4 3.9 4.9 8.1 12.4 16.6 23.2 28.6
Rated input voltage 3-phase 200 V − 15% to 240 V + 10%, 50/60 ± 5%
Rated output
voltage
3-phase 200 to 240 V (The output cannot exceed the incoming voltage).
Rated output
current [A]
CT 1.0 1.6 3.0 5.0 8.0 11.0 17.5 25.0 33.0 47.0 60.0
VT 1.2 1.9 3.5 6.0 9.6 12.0 19.6 30.0 40.0 56.0 69.0
Short-time
deceleration braking
torque (%)
(Discharge Resistor
not connected)
50 50 50 50 50 20 20 20 20 10 10
Braking
Resistor
circuit
*1
Regenerative
braking
Built-in Braking Resistor circuit (separate Discharge Resistor)
Min.
connectable
resistance
[
Ω ]
100 100 100 50 50 35 35 20 17 17 10
Weight [kg] 1.0 1.0 1.1 1.2 1.6 1.8 2.0 3.3 3.4 5.1 7.4
Dimensions (width
× height) [mm]
68 × 128 108 × 128
140 ×
128
140 × 260
180 ×
296
220 ×
350
Dimensions (depth)
[mm]
109
122.5 145.5 170.5 170.5 155 175
*1. The BRD usage is 10%.
