5-2 Basic Functions
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
Take note that the following multi-function input terminals cannot be selected in the light load
mode:
Frequency Reference Selection and Output Frequency Setting
Select the method of the frequency reference.
Since multi-step speed operation (in which a combination pattern of input terminals is used to
specify the speed) is given priority over Frequency Reference Selection (A001), A001 need not
be set. Only when all multi-step speed inputs are OFF and therefore 0th is specified, the
frequency conforms to the setting of A001.
C056
Overtorque Level
(Reverse Regeneration)
P034 Torque Reference Setting
C057
Overtorque Level
(Reverse Power Running)
P036 Torque Bias Mode
C058
Overtorque Level
(Forward Regeneration)
P037 Torque Bias Value
C059
Overtorque/Undertorque Signal
Output Mode Selection
P038 Torque Bias Polarity Selection
H001
Auto-tuning Selection
P039
Speed Limit Value in Torque
Control (forward)
H002/H202
Motor Parameter 1/2
P040
Speed Limit Value in Torque
Control (reverse)
Parameter
No.
Function name
Parameter
No.
Function name
Multi-function input terminals Multi-function output/relay terminals
40: TL Torque limit enabled/disabled 07: OTQ Overtorque/undertorque
41: TRQ1 Torque limit switching 1 10: TRQ During torque limit
42: TRQ1 Torque limit switching 2 −−
52: ATR Torque reference input permission −−
