Omron SYSDRIVE MX2 SERIES User Manual

5-36
5-3 Input/Output Terminals
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
Output Signal Delay/Hold Function
ON delay/OFF delay times can be set for each output terminal.
All output signals immediately turn ON/OFF when the specified conditions are satisfied.
Depending on the selected signal, chattering may occur. In such a case, use this function to
hold or delay the signal.
Set the output terminals (a total of three terminals corresponding to multi-function outputs P1/
EDM and P2 and multi-function relay outputs MA, MB and MC) one by one. For the output
terminals and the corresponding parameters, refer to the table below.
Output terminal ON delay time OFF delay time
P1/EDM C130 C131
P2 C132 C133
Relays (MA, MB, MC) C140 C141
Parameter No. Function name Data
Default
setting
Unit
C130/C132
Output P1/EDM ON
Delay Time
0.0 to 100.0 0.0 s
C131/C133
Output P1/EDM OFF
Delay Time
0.0 to 100.0 0.0 s
C140
Output RY ON Delay
Time
0.0 to 100.0 0.0 s
C141
Output RY OFF Delay
Time
0.0 to 100.0 0.0 s
