6-8 List of Modbus Communication (Modbus-RTU) Data
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
6
Communication Function
6-8 List of Modbus Communication
(Modbus-RTU) Data
R/W in the list shows whether the coil or holding register accepts reading and/or writing.
(R: Read-only, R/W: Can be read and/or written)
(i) Coil Number List
Coil No. Function name R/W Description
0000h Not used − Inaccessible
0001h RUN Command R/W
1: RUN
0: Stop (Enabled when A002/A202 =
03)
0002h Rotation Direction Command R/W
1: Reverse
0: Forward (Enabled when A002/
A202 = 03)
0003h External Trip (EXT) R/W 1: Trips
0004h Trip Reset (RS) R/W 1: Reset
0005h
Reserved −−
0006h
0007h Multi-function Input 1 R/W
1: ON
0: OFF
*1
0008h Multi-function Input 2 R/W
1: ON
0: OFF
*1
0009h Multi-function Input 3 R/W
1: ON
0: OFF
*1
000Ah Multi-function Input 4 R/W
1: ON
0: OFF
*1
000Bh Multi-function Input 5 R/W
1: ON
0: OFF
*1
000Ch Multi-function Input 6 R/W
1: ON
0: OFF
*1
000Dh Multi-function Input 7 R/W
1: ON
0: OFF
*1
000Eh Reserved −−
000Fh Operation Status R
1: RUN
0: Stop (Interlocked with d003)
0010h RUN Direction R
1: Reverse
0: Forward (Interlocked with d003)
0011h Inverter Ready R
1: Ready
0: Not ready
0012h Reserved −−
0013h RUN (during RUN) R
1: During trip
0: Normal
0014h FA1 (constant speed reached) R
1: ON
0: OFF
0015h FA2 (set frequency min. reached) R
1: ON
0: OFF
