Omron SYSDRIVE MX2 SERIES User Manual

5-12
5-1 Monitor Mode
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
DC Voltage Monitor [d102]
The Inverter P-N DC voltage (DC voltage between the Inverter terminals P/+2 and N/-) is
displayed.
During operation, the monitor value changes depending on the actual DC voltage of the
Inverter.
Regenerative Braking Load Rate Monitor [d103]
Displays a regenerative braking load rate. When the displayed value exceeds the value set in
Usage Rate of Regenerative Braking (b090), the Inverter trips because of "E06 (Braking
resistor overload protection)".
Electronic Thermal Load Rate Monitor [d104]
Displays an electronic thermal load rate. When the displayed value exceeds 100%, the Inverter
trips because of "E05 (Overload protection)".
When the power is shut off, the displayed value changes to 0. Also when totaling does not
occur for 10 minutes, the displayed value changes to 0.
Parameter
No.
Function name Data
Default
setting
Unit
d102
DC Voltage
Monitor
0.0 to 999.9/1000.
− V
Parameter
No.
Function name Data
Default
setting
Unit
d103
Regenerative Braking
Load Rate Monitor
0.0 to 100.0
− %
Related functions b090
Parameter
No.
Function name Data
Default
setting
Unit
d104
Electronic Thermal Load
Rate Monitor
0.0 to 100.0
− %
