5-3 Input/Output Terminals
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
Multi-function Input Operation Selection
NO or NC contact can be selected individually for each of multi-function input terminals S1 to
S7/EB.
A terminal with reset (RS) setting functions as NO contact only.
C001 to C007
66
CP1: Position command selection
1
Simple Position Control Mode 5-157
67
CP2: Position command selection
2
68
CP3: Position command selection
3
69 ORL: Zero return limit signal
70 ORG: Zero return startup signal
73 SPD: Speed/position switching
77 GS1: GS1 input (C003 only)
Safety Function 5-167
78 GS2: GS2 input (C004 only)
81
485: Start co-inverter
communication
Inverter-to-Inverter
Communication
6-22
82 Reserved. −−
83
HLD: Retain output frequency Acceleration/Deceleration Hold
Function
5-62
84
ROK: Permission of RUN
command
RUN Permission Signal 5-63
85
EB: Rotation direction detection
(C007 only)
Simple Position Control Function 5-157
86 DISP: Display fixed Fixed Display 5-91
no No: Not assigned −−
Parameter
No.
Data Description Reference item Page
Parameter
No.
Function name Data
Default
setting
Unit
C011 to C017
Multi-function Input
Terminal Operation
Selection
00: NO (NO contact)
00 −
01: NC (NC contact)
C011 to C017 set
values
Status Actual input signal status
Input signal status as
recognized by the
Inverter
00
(NO contact)
Normal
OFF (Open = No conduction)
OFF
Operating
ON (Closed = Conduction)
ON
01
(NC contact)
Normal
ON (Closed = Conduction)
OFF
Operating
OFF (Open = No conduction)
ON
