Appendix-9
Appendix-4 Notes on Compliance with EC Directives and UL/cUL Standards
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
A
Appendix
Appendix-4 Notes on Compliance with EC
Directives and UL/cUL Standards
EC Directives
Notes on EMC (Electromagnetic Compatibility)
CE-EMC Installation Guidelines
You are required to satisfy the EMC directive (2004/108/EC) when using a 3G3MX2 inverter
in an EU country.
To satisfy the EMC directive and to comply with standard, you need to use a dedicated EMC
filter suitable for each model, and follow the guidelines in this section. Following table shows
the compliance condition for reference.
Table 1. Condition for the compliance
Table 2. Applicable EMC filter
Model Cat. Carrier f Motor cable
All 3G3MX2 series C1 2kHz 20m (Shielded)
Input class Inverter model Filter model (Schaffner)
3-phase 200V
class
3G3MX2-A2001
FS24829-8-07
3G3MX2-A2002
3G3MX2-A2004
3G3MX2-A2007
3G3MX2-A2015
FS24829-16-07
3G3MX2-A2022
3G3MX2-A2037 FS24829-25-07
3G3MX2-A2055
FS24829-50-07
3G3MX2-A2075
3G3MX2-A2110 FS24829-70-07
3G3MX2-A2150 FS24829-75-07
1-phase 200V
class
3G3MX2-AB001
FS24828-8-073G3MX2-AB002
3G3MX2-AB004
3G3MX2-AB007
FS24828-27-073G3MX2-AB015
3G3MX2-AB022
