Omron SYSDRIVE MX2 SERIES User Manual

5-24
5-2 Basic Functions
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
Stop Selection
It is possible to select deceleration stop or free-run stop according to the set deceleration time,
when a stop command is issued.
If operation is resumed during free-run operation, the Inverter will restart according to the
method set in Free-run Stop Selection (b088). For details, refer to "Deceleration Stop at Power-
off (Controlled Deceleration on Power Loss Function)" on page 5-106.
Acceleration/Deceleration Time
Set an acceleration/deceleration time for the motor.
The set time indicates the acceleration/deceleration time from 0 Hz to the maximum frequency.
When the LAD (acceleration/deceleration) cancel (LAC) function is selected for a multi-
function input selection and the signal is turned ON, the acceleration/deceleration time
changes to the minimum acceleration/deceleration time (0.01 s) and the output frequency
instantaneously follows the set frequency.
You can also divide the acceleration/deceleration in two steps. For details, refer to "2-step
Acceleration/Deceleration Function (2CH)" on page 5-66.
Parameter
No.
Function name Data
Default
setting
Unit
b091 Stop Selection
00: Deceleration stop
00 −
01: Free-run stop
Parameter
No.
Function name Data
Default
setting
Unit
F002/F202
Acceleration Time Setting
1/2
0.01 to 3600.
Set the acceleration time from 0 to the
maximum frequency.
10.00 s
F003/F203
Deceleration Time
Setting 1/2
0.01 to 3600.
Set the deceleration time from the
maximum frequency to 0.
10.00 s
P031
Acceleration/Deceleration
Time Input Type
00: Digital Operator
00 −
03: Do not set.
C001 to C007
Multi-function Input
Selection
46: LAC (LAD cancel)
−−
Related functions A004/A204, P031, C001 to C007
