Omron SYSDRIVE MX2 SERIES User Manual

7-6
7-1 Error Display and Remedial Actions
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
7
Maintenance Operations
Warning Display
If the set parameter contradicts other set value, a warning will be displayed and the program
LED indicator will flash.
The table below lists the warnings to be displayed and the conditions in which these warnings
are displayed. If a warning is displayed, change the applicable parameter by referring to the
content of the table. (Issuing a RUN command will not rewrite the parameter to the correct
value automatically).
The last displayed warning is stored in d090.
Warning display Warning display condition
v001
Frequency Upper Limit 1 (A061)
>
Maximum Frequency 1 (A004)
v002
Frequency Lower Limit 1 (A062)
>
Maximum Frequency 1 (A004)
v005
Output Frequency Setting (F001), Multi-
step Speed 1 Reference 0 (A020)
>
Maximum Frequency 1 (A004)
v015
Output Frequency Setting (F001), Multi-
step Speed 1 Reference 0 (A020)
>
Frequency Upper Limit 1 (A061)
v025
Frequency Lower Limit 1 (A062)
>
Output Frequency Setting (F001), Multi-
step Speed 1 Reference 0 (A020)
v031
Starting Frequency (b082)
>
Frequency Upper Limit 1 (A061)
v032
Starting Frequency (b082)
>
Frequency Lower Limit 1 (A062)
v035
Starting Frequency (b082)
>
Output Frequency Setting (F001), Multi-
step Speed 1 Reference 0 (A020)
v037
Starting Frequency (b082)
>
Jogging Frequency (A038)
v085
Output Frequency Setting (F001), Multi-
step Speed 1 Reference 0 (A020)
=
Jump frequency
*1
(A063/A065/A067±A064/A066/A068)
v086
Multi-step Speed References 1 to 15
(A021 to A035)
=
v091
Free V/f Frequency 7 (b112)
>
Frequency Upper Limit 1 (A061)
v092
Free V/f Frequency 7 (b112)
>
Frequency Lower Limit 1 (A062)
v095
Free V/f Frequency 7 (b112)
>
Output Frequency Setting (F001), Multi-
step Speed 1 Reference 0 (A020)
v201
Frequency Upper Limit 2 (A261)
>
Maximum Frequency 2 (A204)
v202
Frequency Lower Limit 2 (A262)
>
Maximum Frequency 2 (A204)
v205
Output Frequency Setting (F001), Multi-
step Speed 2 Reference 0 (A220)
>
Maximum Frequency 2 (A204)
v215
Output Frequency Setting (F001), Multi-
step Speed 2 Reference 0 (A220)
>
Frequency Upper Limit 2 (A261)
v225
Frequency Lower Limit 2 (A262)
>
Output Frequency Setting (F001), Multi-
step Speed 2 Reference 0 (A220)
v231
Starting Frequency (b082)
>
Frequency Upper Limit 2 (A261)
v232
Starting Frequency (b082)
>
Frequency Lower Limit 2 (A262)
v235
Starting Frequency (b082)
>
Output Frequency Setting (F001), Multi-
step Speed 2 Reference 0 (A220)
