5-88
5-7 Digital Operator/Operation Functions
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
Display Selection
The items displayed on the Digital Operator can be partially hidden.
This function can also be password-protected. Refer to "Password Function" on page 5-91.
Individual Display of Functions (b037 = 01)
If a specific function is not selected, its relevant parameter is not displayed.
For details on the display requirements, refer to the following table.
Parameter
No.
Function
name
Data
Default
setting
Unit
b037
Display
Selection
00: Complete display
04 −
01: Individual display of functions
02: User setting + b037
03: Data comparison display
04: Basic display
05: Monitor (d***) display only
U001 to U032 User Selection
no: No allocation
no −
d001 to P183
Select the parameter you want to display
(All parameters can be displayed.)
No. Display requirements
Parameters displayed when the
applicable conditions are met
1 Displayed when 2 is set C001 to C007 = 08
F202, F203, A201 to A204, A220, A241 to
A247, A261, A262, A281, A282, A292 to
A296, b212, b213, b221 to b223, C241,
H202 to H206, H220 to H224, H230 to
H234
2
Displayed when Control
method 1 is sensorless
vector control
A044 = 03
d009, d010, d012, b040 to b046, C054 to
C059, H001, H005, H020 to H024, H030 to
H034, P033, P034, P036 to P040
3
Displayed when Control
method 2 is sensorless
vector control
C001 to C007 = 08 and
A244 = 03
d009, d010, d012, b040 to b046, C054 to
C059, H001, H205, H220 to H224, H230 to
H234, P033, P034, P036 to P040
4
Displayed when Control
method 1/2 is free V/f
setting
A044 = 02 or
C001 to C007 = 08 and
A244 = 02
b100 to b113
5
Displayed in the free
electronic thermal mode
b013 = 02 or
C001 to C007 = 08 and
b213 = 02
b015 to b020
6
Displayed when Control
method 1 is free V/f
setting
A044 = 00, 01 A041 to A043, A046, A047
7
Displayed when Control
method 2 is free V/f
setting
C001 to C007 = 08 and
A244 = 00, 01
A241 to A243, A246, A247
To Next Page
