9-31
9-3 Options
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
9
Specifications
Digital Operator (3G3AX-OP01)
External Dimensions Height (55 mm) × Width (70 mm) × Depth (10 mm)
Data display
Operation key
Panel cut dimensions
RUN command LED
indicator
Frequency reference
volume
2-M3, depth 3.5
8.8
18
16.5 15.3
2-φ4
20.5
18
(7)
10 2.7
