5-86
5-7 Digital Operator/Operation Functions
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
Selection of Operation upon Digital Operator Disconnection
If the Inverter detects disconnection of the Digital Operator (= communication with the Digital
Operator has been disrupted for 5 s or more), the Inverter operation conforms to the setting of
Selection of Operation on Digital Operator Disconnection (b165).
Initial Screen Selection (Screen at Power-ON)
The Digital Operator screen to be displayed at power-on can be selected from among the
following: (By factory default, "001 (d001)" is selected.)
Main Built-in Digital Operator
Parameter
No.
Function name Data
Default
setting
Unit
b165
Selection of
Operation on
Digital Operator
Disconnection
00: Trip (E40.
 )
02 −
01: Trip after deceleration stop (E40.
 )
02: Ignore
03: Free-run stop
04: Deceleration stop
Parameter
No.
Function name Data Description (Digital Operator)
Default
setting
Unit
b038
Initial Screen
Selection
000
Screen on which the Enter key
was pressed last (All items other
than d*** and F001 are
parameters.)
*1
001 −
001 d001 (Output Frequency Monitor)
002 d002 (Output Current Monitor)
003 d003 (Rotation Direction Monitor)
: : (Each item corresponds to d***.)
060 d060 (Inverter Mode Monitor)
201 F001 (Output Frequency Setting)
202
Do not set
*1.If "000" is selected and then the power is turned off without changing the setting, this item (b038) will
be displayed the next time the power is turned on.
