5-7
5-1 Monitor Mode
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
Input Power Monitor [d014]
Displays the input power (instantaneous value) of the Inverter.
Integrated Power Monitor [d015]
Displays the integrated power (electric energy) of the Inverter.
The conversion of displayed data is performed with Integrated Power Display Scale (b079).
"d015 display" = "Actual integrated power [kWh]"/"Integrated Power Display Scale (b079)"
Example) If b079 = 100 and the displayed value is 1,000, the actual integrated power is
100,000 [kWh].
The integrated power value can be cleared by setting Integrated Power Clear (b078) to "01."
The integrated power value can also be cleared via terminal input, if "53: KHC (Integrated
power clear)" is allocated to any of the multi-function inputs.
When Integrated Power Display Scale (b079) is set to "1000", up to "999,000,000" [kWh] can
be displayed.
This parameter is saved in the EEPROM when the power is shut off.
Parameter
No.
Function name Data
Default
setting
Unit
d014
Input Power
Monitor
0.0 to 100.0
− kW
Parameter
No.
Function name Data
Default
setting
Unit
d015
Integrated Power
Monitor
0.0 to 9999.
Displayed in increments of the setting
unit 1 kW × (b079).
−−
1000 to 9999
Displayed in increments of the setting
unit 10 kW × (b079).
⎡100 to ⎡999
Displayed in increments of the setting
unit 1,000 kW × (b079).
b078
Integrated Power
Clear
00: Normal
00 −
01: Perform integrated power clear (01
is reset to 00 after the clear.)
b079
Integrated Power
Display Scale
1. to 1000.
1. −
C001 to C007
Multi-function Input
Selection
53: KHC (Integrated power clear)
−−
