Omron SYSDRIVE MX2 SERIES User Manual

5-100
5-8 Restart Functions
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
Reset (RS)
This function resets an Inverter trip.
To reset an Inverter trip, press the STOP/RESET key on the Digital Operator, or turn ON the
reset (RS) terminal.
When using the reset terminal, allocate "18: RS" to a multi-function input terminal.
The restart method to be applied after the reset operation can be selected by Reset Restart
Selection (C103). Take note, however, that the Inverter will restart at 0 Hz if Reset Selection
(C102) is set to "03: Trip reset only," regardless of the setting of C103. If an overcurrent trip
occurs at frequency matching, extend the Restart Standby Time (b003).
A trip reset time can be selected by Reset Selection (C102). In addition, the reset signal can
be applied only to trip reset due to an error.
For the Reset (RS) terminal, only the NO contact setting is effective.
 Do not use the reset terminal to stop the Inverter output. The reset operation will clear various data
such as electronic thermal function and usage rate counter for regenerative braking, thereby
causing damage to the Inverter.
Parameter
No.
Function name Data Description
Default
setting
Unit
b003
Restart Standby
Time
0.3 to
100.0
Time from reset to restart 1.0 s
b007
Frequency
Matching Lower
Limit Frequency
Setting
0.00 to
400.0
If the frequency drops to the set
frequency or below during the motor free
run, the Inverter restarts at 0 Hz.
0.00 Hz
b028
Frequency Pull-
in Restart Level
0.20 ×
Rated
current to
2.00 ×
Rated
current
Current limit level at frequency pull-in
restart
Inverter
rated
current
A
b029
Frequency Pull-
in Restart
Parameter
0.1 to
3000.
Frequency reduction time at frequency
pull-in restart
0.5 s
b030
Starting
Frequency at
Frequency Pull-
in Restart
Selection
00 Frequency at interruption
00 −
01 Maximum frequency
02
Set frequency
C102 Reset Selection
00
Trip reset at power-on (example 1)
Normal: Output shut off
Abnormal: Trip reset
00 −01
Trip reset at power-off (example 2)
Normal: Output shut off
Abnormal: Trip reset
02
Trip reset at power-on (example 1)
Normal: Disabled
Abnormal: Trip reset
