Omron SYSDRIVE MX2 SERIES User Manual

5-32
5-3 Input/Output Terminals
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
Input Terminal Response Time
A sampling time can be set individually for each of multi-function input terminals S1 to S7/EB.
Helps remove chattering and other noises. If the terminal input becomes unstable because of
chattering, etc. increase the data value.
The larger the data value is, the slower the response time. A setting range of 0 to 200 is
available, which corresponds to approx. 2 to 400 ms.
Note. The response time is ignored upon power ON or reset. For example, if the power is turned on while
the FW terminal is still ON, operation resumes immediately regardless of the set value of response
time.
Multi-function Output Terminal Selection
The following functions can be allocated to Multi-function Output Terminal P1/EDM to P2
Selections (C021 to C022) and Multi-function Relay Output (MA, MB) Function Selection
(C026). Multi-function output terminals P1/EDM, P2 are open-collector output, while multi-
function relay output terminal MA, MB are relay output.
NO or NC contact can be selected individually for each output terminal using C031, C032 or
C036.
Parameter
No.
Function name Data
Default
setting
Unit
C160 to C166
Input Terminal
Response Time
0. to 200. (× 2 ms)
Approx. 2 to 400 ms
1. ms
Data Description Reference item Page
00 RUN: During RUN Signal During RUN 5-121
01 FA1: Constant speed reached Frequency Arrival Signal
5-122
02 FA2: Set frequency min. reached
03 OL: Overload warning Overload Limit/Overload Warning 5-115
04 OD: PID excessive deviation PID Function 5-73
05 AL: Alarm output Alarm Signal 5-119
06
FA3: Meet designated frequency
during accel./decel.
Frequency Arrival Signal
5-122
07 OTQ: Overtorque/Undertorque Overtorque/undertorque 5-152
09
UV: Signal during undervoltage Restart Upon Momentary Power Interruption/
Undervoltage, Overvoltage/Overcurrent
5-96
10 TRQ: During torque limit Torque Limit Function 5-153
11 RNT: RUN time over RUN/Power ON Time Exceeded
5-124
12 ONT: Power on time over
13 THM: Thermal warning Electronic Thermal Function 5-113
19 BRK: Brake release Brake Control Function
5-142
20 BER: Brake error
21 ZS: 0Hz 0-Hz Signal (ZS) 5-125
