Omron SYSDRIVE MX2 SERIES User Manual

5-33
5-3 Input/Output Terminals
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
22 DSE: Excessive speed deviation Simple Position Control Mode
5-159
23 POK: Position ready
24 FA4: Set frequency exceeded 2 Frequency Arrival Signal
5-122
25
FA5: Meet designated frequency 2
during accel./decel.
26 OL2: Overload warning 2 Overload Limit/Overload Warning 5-115
27
FVdc: Analog FV disconnection
detection
Window Comparator Function
5-132
28
FIdc: Analog FI disconnection
detection
31 FBV: PID FB status output PID Function 5-73
32
NDc: Communication disconnection
detection
RS485
5-128
33 LOG1: Logic operation output 1 Logic Operation Function
5-12534 LOG2: Logic operation output 2
35 LOG3: Logic operation output 3
39 WAC: Capacitor life warning Capacitor Life Warning Signal 5-126
40 WAF: Cooling fan life warning signal WAF: Cooling Fan Life Warning Signal 5-127
41 FR: Starting contact signal Starting Contact Signal 5-128
42 OHF: Fin overheat warning Cooling Fin Overheat Warning 5-129
43 LOC: Low current signal Low Current Signal 5-129
44
Reserved. −−45
46
50 IRDY: Operation ready Operation Ready Signal 5-130
51 FWR: During forward operation Signal During Forward Operation 5-130
52
RVR: During reverse operation Signal During Reverse Operation
5-131
53
MJA: Fatal fault signal Fatal Fault Signal
5-131
54 WCFV: Window comparator FV Window Comparator Function
5-132
55 WCFI: Window comparator FI
58
FREF: Frequency command source Frequency Reference Selection Status
Signal
5-133
59 REF: RUN command source RUN Command Status Signal 5-133
60 SETM: Motor 2 selection Motor 2 Control Selected Signal 5-134
62 EDM: Safety device monitor Safety Function 5-167
63 Reserved. −−
255 no: Not assigned −−
Data Description Reference item Page
