7-1 Error Display and Remedial Actions
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
7
Maintenance Operations
Error Code List
Name Description
Error
code
Check point and remedy
Reference
page
Overcurrent
protection
If the motor is restrained or
rapidly accelerated or
decelerated, a large current
will flow through the Inverter,
which will result in breakage.
Accordingly, the protection
circuit operates at
approximately 200% of the
Inverter rated output current
and a trip occurs.
Constant
speed
E01.
 Is there any rapid load
fluctuation?
→
Eliminate load fluctuation.
Is there any output short-circuit?
→ Check the output wiring.
Is there any ground fault?
→Check the output
wiring and motor.
−
During
deceleration
E02.  Is there any rapid deceleration?
→Increase the
deceleration time.
5-24
5-66
Acceleration E03.  Is there any rapid acceleration?
→Increase the
acceleration time.
Has the motor been locked?
→Check the motor and
wiring.
Is the torque boost too high?
→ Lower the torque boost.
Others E04.  Is the DC injection braking
too high?
→
Decrease the braking force.
5-135
Overload
protection
*1
The Inverter output current is monitored
and if a motor overload is detected by
the built-in electronic thermal, a trip
occurs.
E05.  Is the load too large?
→Decrease the load rate.
Is the thermal level correct?
→Adjust the thermal level
to an appropriate level.
5-110
Braking
resistor
overload
protection
A trip will occur if the usage rate of
regenerative braking circuit exceeds
the b090 set value.
E06.  Is there any rapid deceleration?
→Increase the
deceleration time.
Is the operation cycle too short?
→Increase the operation
cycle.
5-24
5-141
Overvoltage
protection
Extremely high DC voltage between P/
+2 and N/− may result in
failure.Accordingly, a trip will occur if
the DC voltage between P/+2 and N/−
reaches approx. 400 VDC (200V class)
or 800 VDC (400V class) or above due
to increase in the regenerative energy
from the motor or in the incoming
voltage.
E07.
 Is there any rapid deceleration?
→Increase the
deceleration time.
Is there any ground fault?
→Check the output
wiring and motor.
Has the motor been rotated
from the load side?
→Reduce regenerative
energy.
Has incoming voltage
increased?
→
Lower the incoming
voltage, sustain the power
supply fluctuation, apply
the AC reactor to input.
−
*1. The reset command will not be accepted until approximately 10 seconds pass since the trip occurs
(protection function works).
