5-42
5-4 Analog Signal
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
MP Terminal (Pulse/PWM Output)
The MP terminal is a 10 VDC pulse output or PWM output.
The output frequency and output current can be monitored using the MP terminal on the control
circuit terminal block.
MP Selection
Select a signal to output from the following table.
If pulse output 03, 08 or 15 is selected, use the digital frequency counter. For other output
signals, use the analog meter.
Parameter
No.
Data Description
PWM/
pulse
Full-scale value
C027
00 Output frequency
*1
PWM 0 to maximum frequency [Hz]
01 Output current PWM 0 to 200%
02 Output torque
*2
PWM 0 to 200%
03 Digital output frequency
*3
Pulse 0 to maximum frequency [Hz]
04
Output voltage
PWM
0 to 133%
(Example: 7.5 V at 200 V for a 200 V
class)
05 Input power PWM 0 to 200%
06 Electronic thermal load rate PWM 0 to 100%
07 LAD frequency
*1
PWM 0 to maximum frequency [Hz]
08
Digital current monitor
Pulse
Refer to "MP Gain Setting" on page 5-
43.
10
Cooling fin temperature
PWM
0 to 200°C (0°C output at 0°C or
lower)
12 Do not set. −−
15
Pulse train input monitor
Pulse
Refer to "MP Gain Setting" on page 5-
43.
16 Do not set. −−
*1."07: LAD frequency" is the frequency reference issued by the Inverter and corresponds to Output
Frequency Monitor (d001)."00: Output frequency" is the value that is calculated reflecting vector control
compensation and stabilization control under sensorless vector control, etc.
*2.This setting is effective only when the control method is Sensorless Vector Control (A044/A244 = 03).
*3.If Frequency Conversion Coefficient (b086) is set, a gain-converted value is output for the digital output
frequency. Refer to "Output Frequency Monitor [d001]" on page 5-1.
