Omron SYSDRIVE MX2 SERIES User Manual

5-4
5-1 Monitor Mode
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
Output Frequency Monitor (After Conversion) [d007]
Displays a conversion value based on the coefficient set in Frequency Conversion Coefficient
(b086).
This monitor is used to change the unit of displayed data (e.g. motor rpm).
"Display of the Output Frequency Monitor (d007)" = "Output Frequency Monitor (d001)" ×
"Frequency Conversion Coefficient (b086)"
Example) Displaying rpm of 4-pole motor.
Motor rpm N [min-1] = (120 × f [Hz])/P [pole] = f [Hz] × 30
As such, when b086 = 30.0, a motor rpm of 1800 (60 × 30.0) is displayed at 60 Hz.
Note: Data in ( ) indicates the value when the high-frequency mode is selected.
 If Frequency Reference Selection is set to Digital Operator (A001 = 02), enabling d001/d007
Frequency Setting Mode Selection (b163 = 01) lets you change the Output Frequency Monitor
(d001) setting using the Increment/Decrement keys only during operation.
 Changed Output Frequency (d001) will be reflected to the Output Frequency Setting (F001).
Pressing the Enter key stores the setting in the EEPROM.
 Since F001 is rewritten while d007 is still displayed, there may be a time gap between the key
operation and display change depending on the acceleration/deceleration time.
 While the PID function is activated or being stopped, the output frequency cannot be changed.
 The frequency cannot be changed in the individual input mode by pressing the Increment/
Decrement keys simultaneously.
Parameter
No.
Function name Data
Default
setting
Unit
d007
Output Frequency
Monitor (after
conversion)
0.00 to 99.99 (Displayed in increments of
0.01.)
−−
100.0 to 999.9 (Displays in increments of
0.1.)
1000. to 4000 (9999) (Displays in
increments of 1.)
1,000 to 9,999 (Displayed in increments
of 10.)
(⎡100) (Displays in increments of 1000.)
b086
Frequency
Conversion
Coefficient
0.01 to 99.99
Set in increments of 0.01.
(d007 = d001 × b086)
1.00 −
b163
d001/d007
Frequency Setting
Mode Selection
00: Disabled
(The output frequency cannot be
changed using d001/d007.)
00 −
01: Enabled
(The output frequency can be
changed using d001/d007.)
