5-5 Settings Relating to Control Method
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
Motor 2 Control Function (SET)
The motors specified by two different parameters can be switched and controlled accordingly.
Switch between the two motors can be conducted by allocating "08: SET" to Multi-function
Input Selections (C001 to C007) and then turning the SET terminal ON/OFF. (OFF: Motor 1
control, ON: Motor 2 control)
The functions switchable via the SET terminal are as follows:
Parameter
No.
Function name Data
Default
setting
Unit
C001 to C007
Multi-function
Input Selection
08: SET (Motor 2 control)
−−
Motor 1
control
Motor 2
control
Setting item
F001 Output Frequency Setting
F002 F202 Acceleration Time Setting
F003 F203 Deceleration Time Setting
A001 A201 Frequency Reference Selection
A002 A202 RUN Command Selection
A003 A203 Base Frequency
A004 A204 Maximum Frequency
A020 A220 Multi-step Speed Reference 0
A041 A241 Torque Boost Selection
A042 A242 Manual Torque Boost Voltage
A043 A243 Manual Torque Boost Frequency
A044 A244 Control Method
A045 A245 Output Voltage Gain
A046 A246 Automatic Torque Boost Voltage Compensation Gain
A047 A247 Automatic Torque Boost Slip Compensation Gain
A061 A261 Frequency Upper Limit
A062 A262 Frequency Lower Limit
A081 A281 AVR Selection
A082 A282 Motor Incoming Voltage Selection
A092 A292 Acceleration Time 2
A093 A293 Deceleration Time 2
A094 A294 2-step Acceleration/Deceleration Selection
A095 A295 2-step Acceleration Frequency
A096 A296 2-step Deceleration Frequency
b012 b212 Electronic Thermal Level
b013 b213 Electronic Thermal Characteristics Selection
b021 b221 Overload Limit Selection
