Omron SYSDRIVE MX2 SERIES User Manual

5-101
5-8 Restart Functions
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
Example 1) Trip reset at power ON (C102 = 00, 02, 03)
Example 2) Trip reset at power OFF (C102= 01)
Example 3) Reset enabled when normal (C102 = 00, 01)
Example 4) Reset disabled when normal (C102 = 02, 03)
C102 Reset Selection 03
Trip reset only (example 1)
Not initializing internal data such as
current values upon trip reset (Refer to
"Initialization Setting" on page 5-171.)
Normal: Disabled
Abnormal: Trip reset
00 −
C103
Reset Restart
Selection
00 0 Hz restart
00 −01 Frequency matching restart (example 3)
02 Frequency pull-in restart (example 4)
C001 to
C007
Multi-function
Input Selection
18
RS: Reset
−−
Parameter
No.
Function name Data Description
Default
setting
Unit
RS input
AL output
(alarm signal)
RS input
AL output
(alarm signal)
Restarts according to C103.
Output frequency
RUN command
RS input
Output frequency
RUN command
RS input
Reset is disabled during operation.
