5-3 Input/Output Terminals
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
C001 to C007
20 STA: 3-wire start
3-wire Input Function 5-5621 STP: 3-wire stop
22 F/R: 3-wire forward/reverse
23 PID: PID disabled
PID Function 5-73
24 PIDC: PID integral reset
27
UP: UP/DWN function
accelerated
Remote Operation Function 5-71
28
DWN: UP/DWN function
decelerated
29 UDC: UP/DWN function data clear
31 OPE: Forced operator Forced Digital Operator Function 5-85
32 SF1: Multi-step speed bit 1
Multi-step Speed Operation
Function (Bit)
5-65
33 SF2: Multi-step speed bit 2
34 SF3; Multi-step speed bit 3
35 SF4: Multi-step speed bit 4
36 SF5: Multi-step speed bit 5
37 SF6: Multi-step speed bit 6
38 SF7: Multi-step speed bit 7
39
OLR: Overload limit switching Overload Limit/Overload
Warning
5-114
40 TL: Torque limit enabled/disabled
Torque Limit Function 5-15341 TRQ1: Torque limit switching 1
42 TRQ2: Torque limit switching 2
44 BOK: Brake confirmation Brake Control Function 5-142
46
LAC: LAD cancel Acceleration/Deceleration
Function
5-24
47 PCLR: Position deviation clear Simple Position Control Function 5-157
50 ADD: Frequency addition Frequency Addition Function 5-71
51 F-TM: Forced terminal block Forced Terminal Block Function 5-85
52
ATR: Torque reference input
permission
Torque Control 5-155
53 KHC: Integrated power clear Integrated Power Monitor 5-7
56
Reserved. −−
57
58
59
60
61
62
65 AHD: Analog command held Analog Command Hold Function 5-39
Parameter
No.
Data Description Reference item Page
