Omron SYSDRIVE MX2 SERIES User Manual

5-45
5-4 Analog Signal
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
AM Gain Setting
Set the Inverter output gain according to the meters connected to the AM and AMI terminals.
Note: When a reset signal is input, the offset becomes 0% once.
Example) AM provides 4 to 20 mA output, the offset value is 20% (= 4 / 20). (Default value)
Parameter
No.
Function name Data
Default
setting
Unit
C106
AM Gain
Adjustment
50. to 200.
Set a gain for the AM monitor.
100. %
C109 AM Bias Setting
0 to 100
Set an offset for the AM monitor.
0. %
