5-11 Sensorless Vector Control
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
5
Functions
* These parameters are measured automatically when offline auto-tuning is performed. They can also be
changed to desired value manually after tuning.
 If H002/H202 remains 00 after the completion of auto-tuning, the motor parameters obtained by
auto-tuning are not reflected in the operation data.
 If the auto-tuning result indicates that the tuning was aborted, perform auto-tuning again.
 If a trip occurs during auto-tuning, the auto-tuning processing is forced to stop.
(No abort message appears. Trip display is given higher priority.)
After removing the cause of the trip, set H001 to 01 and then perform the auto-tuning again.
 If the offline auto-tuning is performed with "free V/f setting" selected as the control method, the
Inverter displays the abort message and stops processing.
 During auto-tuning, the deceleration stop tends to slow under certain conditions such as when the
incoming voltage is high. In this case, press the STOP key and adjust the parameters so that the
value of Over voltage Suppression Integral Time Setting (b134) will decrease and the value of
Overvoltage Suppression Level During Deceleration (b131) will increase.
 If an overcurrent trip occurs during acceleration while auto-tuning is in progress, adjust the
Parameter
No.
Function name Data
Default
setting
Unit
H001 Auto-tuning Selection
00: Disabled
00 −
01: Enabled (Motor does not
rotate)
02: Enabled (Motor rotates)
H002/H202 Motor Parameter 1/2
00: Standard motor parameter
00 −
02: Auto-tuning parameter
H003/H203 Motor Capacity 1/2 0.1 to 18.5
Default
setting
kW
H004/H204 Motor Pole Number 1/2 2/4/6/8/10 4 pole
H030/H230
Motor 1/2 Parameter R1
(auto-tuning data)
0.001 to 65.53
*
(Primary resistance)
Depends
on the
capacity
Ω
H031/H231
Motor 1/2 Parameter R2
(auto-tuning data)
0.000 to 65.53
*
(Secondary resistance)
Depends
on the
capacity
Ω
H032/H232
Motor 1/2 Parameter L
(auto-tuning data)
0.00 to 655.3
*
(Leakage inductance)
Depends
on the
capacity
mH
H033/H233
Motor 1/2 Parameter Io
(auto-tuning data)
0.00 to 655.3
*
(No-load current)
Depends
on the
capacity
A
H034/H234
Motor 1/2 Parameter J
(auto-tuning data)
0.001 to 9999.
*
(Moment of inertia)
Depends
on the
capacity
kgm
2
A003/A203 Base Frequency 1/2 30.0 to Maximum Frequency 1/2 60.0 Hz
A051
Internal DC Injection Braking
Selection
00: Disabled
00 −
01: Enabled
A082/A282
Motor Incoming Voltage
Selection 1/2
200/215/220/230/240
This function can be selected for
200V class models.
200 V
380/400/415/440/460/480
This function can be selected for
400V class models.
400 V
Related functions b046
