6-52
6-8 List of Modbus Communication (Modbus-RTU) Data
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
6
Communication Function
137Bh
Brake Control Function
Selection
b120 R/W
00: Disabled
01: Enabled
−
5-143
137Ch
Brake Release Wait
Time
b121 R/W 0 to 500 0.01 [s]
137Dh
Acceleration Wait Time b122 R/W 0 to 500 0.01 [s]
137Eh Stop Wait Time b123 R/W 0 to 500 0.01 [s]
137Fh
Brake Wait Time for
Confirmation
b124 R/W 0 to 500 0.01 [s]
1380h
Brake Release
Frequency
b125 R/W 0 to 40000 0.01 [Hz]
5-143
1381h Brake Release Current b126 R/W 0 to 20000 0.01 [%]
1382h Break ON Frequency b127 R/W 0 to 40000 0.01 [Hz]
1383h
Reserved −−− − −
1384h
1385h
Overvoltage
Suppression Function
Selection During
Deceleration
b130 R/W
00: Disabled
01: Enabled (DC voltage
kept constant)
02: Enabled (Acceleration
enabled)
−
5-117
1386h
Overvoltage
Suppression Level
During Deceleration
b131 R/W
200 V class: 330 to 390
400 V class: 660 to 780
1 [V]
1387h
Overvoltage
Suppression Parameter
b132 R/W 10 to 3000 0.01 [s]
1388h
Overvoltage
Suppression
Proportional Gain Setting
b133 R/W 0 to 500 0.01
1389h
Overvoltage
Suppression Integral
Time Setting
b134 R/W 0 to 1500 0.1 [s]
138Ah
to
1393h
Reserved −−− − −
1394h
GS Input Operation
Selection
b145 R/W
00: Do not trip
01: Tripped
− 5-168
1395h
to
1398h
Reserved −−− − −
1399h
Main Panel Display
Selection
b150 R/W
0 to 60h (BCD) (d001 to
d060)
− 5-87
139Ah
to
13A2h
Reserved −−− − −
13A3h d050 Monitor Target 1 b160 R/W
0 to 30h (BCD) (d001 to
d030)
−
5-10
13A4h d050 Monitor Target 2 b161 R/W
0 to 30h (BCD) (d001 to
d030)
−
13A5h Reserved −−− − −
13A6h
d001/d007 Frequency
Setting Mode Selection
b163 R/W
00: Disabled
01: Enabled
−
5-1
5-4
13A7h
Initial Screen Automatic
Swi
tching Function
b164 R/W
00: Disabled
01: Enabled
− 5-87
Register
No.
Function name
Parameter
No.
R/W
Monitor and setting
parameters
Data
resolution
Page
