9-5
9-1 Standard Specification List
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
9
Specifications
Note 1. The applicable motor is a 3-phase standard motor. For using any other type, be sure that the rated
current does not exceed that of the Inverter.
Note 2. Output voltage decreases according to the level of the power supply voltage.
Note 3. The braking torque at the time of capacitor feedback is an average deceleration torque at the
shortest deceleration (when it stops from 50 Hz). It is not a continuous regeneration torque. Also,
the average deceleration torque varies depending on the motor loss. The value is reduced in
operation over 50 Hz.
Other functions
AVR function, V/f characteristics switching, upper/lower limit, 16-step speeds, starting frequency
adjustment, jogging operation, carrier frequency adjustment, PID control, frequency jump, analog
gain/bias adjustment, S shape acceleration/deceleration, electronic thermal characteristics, level
adjustment, restart function, torque boost function, fault monitor, soft lock function, frequency
conversion display, USP function, motor 2 control function, UP/DWN, overcurrent suppression
function, etc.
General specifications
Ambient
temperature
−10 to 50°C (However, derating is required).
Ambient storage
temperature
−20°C to 65°C (short-time temperature during transport)
Humidity 20% to 90% RH (with no condensation)
Vibration 5.9 m/s
2
(0.6G), 10 to 55 Hz
Location At a maximum altitude of 1,000 m; indoors (without corrosive gases or dust)
Options
DC reactor, AC reactor, radio noise filter, input noise filter, output noise filter,
regenerative braking unit, Braking Resistor, EMC noise filter, etc.
*1. Protection method complies with JEM 1030.
*2. To operate the motor at over 50/60 Hz, contact the motor manufacturer to find out the maximum
allowable speed of revolution.
*3. For the stable control of the motor, the output frequency may exceed the maximum frequency set in
A004 (A204) by 2 Hz max.
Function name Specifications
