Omron SYSDRIVE MX2 SERIES - Page 420

9-27
9-3 Options
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
9
Specifications
Specifications
Power
supply
Model
Rated
current
(A)
Inverter model
External Dimensions
(H × W × D) (mm)
Weight
(kg)
3-phase AC
200 V class
1-phase AC
200 V class
3-phase AC
400 V class
3-phase,
3-wire
Rated
voltage
500 VAC
3G3AX-NFO01 6
3G3MX2-A2001
/-A2002/-A2004
3G3MX2-AB001
/-AB002
3G3MX2-A4004
/-A4007
156 × 95 × 50 0.7
3G3AX-NFO02 12
3G3MX2-A2007
/-A2015
3G3MX2-AB004
/-AB007
3G3MX2-A4015
/-A4022/-A4030
176 × 110 × 70 0.9
3G3AX-NFO03 25
3G3MX2-A2022
/-A2037
3G3MX2-AB015
/-AB022
3G3MX2-A4040
/-A4055/-A4075
154 × 160 × 120 2.1
3G3AX-NFO04 50
3G3MX2-A2055
/-A2075
−
3G3MX2-A4110
/-A4150
210 × 200 × 150 3.7
3G3AX-NFO05 75 3G3MX2-A2110 −−230 × 220 × 170 5.7
3G3AX-NFO06 100 3G3MX2-A2150 −−237 × 220 × 170 8.4
