Omron SYSDRIVE MX2 SERIES User Manual

9-29
9-3 Options
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
9
Specifications
Specifications
Model Inverter model
Motor
capacity
Dimensions (mm)
Weight
(kg)
VT CT A C D E H H1 X Y
3G3AX-AL2025
3G3MX2-A2001
√√
130 82 60 40 150 92 50 67 2.8
3G3MX2-A2002
√√
3G3MX2-A2004
√√
3G3MX2-A2007
√√
3G3MX2-AB001
√√
3G3MX2-AB002
√√
3G3MX2-AB004
√√
3G3AX-AL2055
3G3MX2-A2015
√√
140 98 60 40 150 92 50 75 4.0
3G3MX2-A2022
√√
3G3MX2-AB007
√√
3G3MX2-AB015
*1
−√
3G3AX-AL2110
3G3MX2-A2037
√√
160 103 70 55 170 106 60 80 5.0
3G3MX2-A2055
*1
−√
3G3MX2-AB015
√√
3G3MX2-AB022
√√
3G3AX-AL2220
3G3MX2-A2055
√√
180 113 75 55 190 138 90 90 10.0
3G3MX2-A2075
√√
3G3MX2-A2110
*1
−√
3G3AX-AL2330
3G3MX2-A2110
√√
180 113 85 60 230 138 125 90 11.0
3G3MX2-A2150
√√
