3-6
3-1 Name of Parts of the Digital Operator
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
3
Operation
Operation Example When the Digital Operator is Connected to the Conventional Model
Although operations can be performed by connecting the conventional Digital Operator model
(3G3AX-OP01) to the 3G3MX2, the operations associated with the Mode key and Enter key
vary from that of the conventional key operation system. To switch to the parameter display to
data display, use the Enter key instead of the Mode key. Take note that pressing the FUNC
key while a parameter is displayed means moving the function group.
Key Operation System When the Conventional Digital Operator Model (3G3AX-OP01)
is Connected to the 3G3MX2
(Reference) Key Operation System of the 3G3MX2 Digital Operator
(Reference) Key Operation System When the Conventional Digital Operator Model (3G3AX-
OP01) is Connected to the Conventional Model
ak0k0k1
bk0k0k1
Move the function
group
Move to data display
Return without saving
the changes
Return after saving the changes
0k2
0k1
Conventional model 3G3AX-OP01
ak0k0k1
3G3MX2
ak0k0k1
bk0k0k1
Move the function
group
0k2
0k1
Move to data display
Return without saving the changes
Return after saving the changes
3G3MX2 Digital Operato
r
ak0k0k1
ak-k-k-
bk0k0k1
No applicable
function
ak0k0k1
0k2
0k1
Move to data display
Return without saving
the changes
Return after saving the changes
Conventional model 3G3AX-OP01
ak0k0k1
Conventional model
3G3MX, etc.
