4-7
4-2 Function Mode
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
4
Parameter List
Multi-step speed/jogging
A034
Multi-step
Speed
Reference 14
0.00
Starting frequency to
Maximum Frequency
0.00
yes yes Hz 5-63
A035
Multi-step
Speed
Reference 15
0.00
A038
Jogging
Frequency
Starting frequency to 9.99 0.00 yes yes Hz
5-59
A039
Jogging Stop
Selection
00: Free run on jogging stop/
Disabled during operation
01: Deceleration stop on
jogging stop/Disabled
during operation
02: DC injection braking on
jogging stop/Disabled in
operation
03: Free run on jogging stop/
Enabled in operation
04: Deceleration stop on
jogging stop/Enabled in
operation
05: DC injection braking on
jogging stop/Enabled in
operation
04 no yes −
V/f characteristics
A041
Torque Boost
Selection 1
00: Manual torque boost
01: Automatic torque boost
00 no no −
5-49
A241
Torque Boost
Selection 2
00: Manual torque boost
01: Automatic torque boost
00 no no −
A042
Manual Torque
Boost Voltage 1
0.0 to 20.0 (Percentage of
motor voltage A082)
1.0 yes yes %
A242
Manual Torque
Boost Voltage 2
0.0 to 20.0 (Percentage of
motor voltage A282)
1.0 yes yes %
A043
Manual Torque
Boost
Frequency 1
0.0 to 50.0 (Ratio to base
frequency A003)
5.0 yes yes %
A243
Manual Torque
Boost
Frequency 2
0.0 to 50.0 (Ratio to base
frequency A203)
5.0 yes yes %
A044
Control Method
1
00: Constant torque
characteristics (VC)
01: Reduced torque
characteristics (VP 1.7th
power <VC, if low speed>)
02: Free V/f setting
03: Sensorless vector control
(heavy load only)
00 no no −
5-46
5-144
Parameter No. Function name Monitor or data range
Default
setting
Set data
Data can
be set
during
RUN
Data can be
changed
during RUN
Unit Page
