4-28
4-2 Function Mode
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
4
Parameter List
Analog monitor
C027 MP Selection
00: Output frequency
01: Output current
02: Output torque
03: Digital output frequency
04: Output voltage
05: Input power
06: Electronic thermal load
rate
07: LAD frequency
08: Digital current monitor
10: Cooling fin temperature
12: Do not set.
15: Pulse train input monitor
16: Do not set.
07 no yes − 5-42
C028 AM Selection
00: Output frequency
01: Output current
02: Output torque
04: Output voltage
05: Input power
06: Electronic thermal load
rate
07: LAD frequency
10: Cooling fin temperature
11: Output torque (signed)
16: Do not set.
07 no yes − 5-44
C030
Digital Current
Monitor
Reference
Value
0.20 × rated current to 2.00 ×
rated current (current value at
digital current monitor output
1,440 Hz)
Rated
current
yes yes A 5-43
Multi-function output terminal
C031
Multi-function
Output Terminal
P1/EDM Contact
Selection
00: NO contact at P1, P2, MA,
NC contact at MB
01: NC contact at P1, P2, MA,
NO contact at MB
00 no yes
− 5-34
C032
Multi-function
Output Terminal
P2 Contact
Selection
00 no yes
C036
Multi-function
Relay Output
(MA, MB)
Contact
Selection
01 no yes
Parameter No. Function name Monitor or data range
Default
setting
Set data
Data can
be set
during
RUN
Data can be
changed
during RUN
Unit Page
