Omron SYSDRIVE MX2 SERIES - Page 97

4-30
4-2 Function Mode
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-Axxxx)
4
Parameter List
Level and output terminal status
C054
Overtorque/
Undertorque
Selection
00: Overtorque
01: Undertorque
00 no yes −
5-152
C055
Overtorque
Level (Forward
Power
Running)
0. to 200.
100. no yes
%
C056
Overtorque
Level (Reverse
Regeneration)
100. no yes
C057
Overtorque
Level (Reverse
Power
Running)
100. no yes
C058
Overtorque
Level (Forward
Regeneration)
100. no yes
C059
Overtorque/
Undertorque
Signal Output
Mode Selection
00: Enabled during
acceleration/deceleration
and constant speed
01: Enabled only during
constant speed
01 no yes −
C061
Electronic
Thermal
Warning Level
0. to 100. 90. no yes % 5-113
C063
0 Hz Detection
Level
0.00 to 99.99
100.0
0.00 no yes Hz 5-125
C064
Cooling Fin
Overheat
Warning Level
0. to 110. 100. no yes °C5-129
Communication function
C071
Communication
Speed
Selection
03: 2,400 bps
04: 4,800 bps
05: 9,600 bps
06: 19.2 kbps
07: 38.4 kbps
08: 57.6 kbps
09: 76.8 kbps
10: 115.2 kbps
05 no yes −
6-3
C072
Communication
Station No.
Selection
1. to 247. 1. no yes −
C074
Communication
Parity Selection
00: No parity
01: Even
02: Odd
00 no yes −
C075
Communication
Stop Bit
Selection
1: 1 bit
2: 2 bits
1noyes−
Parameter No. Function name Monitor or data range
Default
setting
Set data
Data can
be set
during
RUN
Data can be
changed
during RUN
Unit Page
