Oracle X7-2 Service Manual

Servicing PCIe Risers (CRU)
This section describes how to service PCIe risers. PCIe risers are customer-replaceable units
(CRUs) that require you to power off the server. For more information about CRUs, see
“Illustrated Parts Breakdown” on page 19 and “Customer-Replaceable Units” on page 21.
PCIe cards in all slots are installed on vertical risers. You must remove the associated riser to
remove and replace a PCIe card. You must remove all three PCIe risers when replacing the
motherboard.
Caution - These procedures require that you handle components that are sensitive to
electrostatic discharge. This sensitivity can cause the components to fail. To avoid
damage, ensure that you follow antistatic practices as described in “Electrostatic Discharge
Safety” on page 50.
Caution - Ensure that all power is removed from the server before removing or installing PCIe
risers, or damage to the PCIe cards installed in the risers might occur. You must disconnect all
power cables from the system before performing these procedures.
The following sections provide information to assist you in servicing PCIe risers:
■
“PCIe Riser Location and Differences” on page 112
■
“Remove a PCIe Riser From PCIe Slot 1 or 2” on page 113
■
“Install a PCIe Riser Into PCIe Slot 1 or 2” on page 114
■
“Remove the PCIe Riser From PCIe Slots 3 and 4” on page 116
■
“Install the PCIe Riser Into PCIe Slots 3 and 4” on page 118
Related Information
■
“Servicing PCIe Cards (CRU)” on page 121
Servicing PCIe Risers (CRU) 111

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
