Oracle X7-2 Service Manual

Remove the Server Top Cover
Place electrostatic discharge (ESD)-sensitive components such as the printed circuit boards on
an antistatic mat. The following items can be used as an antistatic mat:
■
An antistatic bag used to wrap a replacement part
■
An Oracle ESD mat (orderable item)
■
A disposable ESD mat (shipped with some replacement parts or optional system
components)
2.
Attach an antistatic wrist strap.
When servicing or removing server components, attach an antistatic strap to your wrist and then
to a metal area on the chassis. Then disconnect the power cords from the server.
Note - An antistatic wrist strap is not included in the Ship Kit for the server. However, antistatic
wrist straps might be included with options and components.
Related Information
■
“Remove Antistatic Measures” on page 211
Remove the Server Top Cover
Servicing some components requires that the top cover be removed.
1.
Ensure that the AC power cords are disconnected from the server power
supplies.
Note - Fan modules are hot-pluggable and do not require AC power cables to be disconnected
from the server power supplies.
62 Oracle Server X7-2 Service Manual • October 2017

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
