Oracle X7-2 Service Manual

Servicing an Internal USB Flash Drive (CRU)
This section describes how to service a USB flash drive. The USB flash drive is a customer-
replaceable unit (CRU) that requires you to power off the server. For more information
about CRUs, see “Illustrated Parts Breakdown” on page 19 and “Customer-Replaceable
Units” on page 21.
Caution - These procedures require that you handle components that are sensitive to static
discharge. This sensitivity can cause the component to fail. To avoid damage, ensure that you
follow antistatic practices as described in “Electrostatic Discharge Safety” on page 50.
Caution - Ensure that all power is removed from the server before removing or installing a
flash drive or damage to the drive might occur. You must disconnect all power cables from the
system before performing these procedures.
This section covers the following procedures:
■
“Remove an Internal USB Flash Drive” on page 93
■
“Install an Internal USB Flash Drive” on page 94
Related Information
■
“USB Ports” on page 221
Remove an Internal USB Flash Drive
The server can be equipped with one internal USB flash drive.
1.
Prepare the server for service.
a.
Power off the server, and disconnect the power cords from the power
supplies.
See “Powering Down the Server” on page 53.
Servicing an Internal USB Flash Drive (CRU) 93

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
