Oracle X7-2 Service Manual

Servicing the Internal M.2 Flash SSDs (CRU)
This section describes how to service M.2 flash solid-state drives (SSDs). M.2 flash SSDs
are customer-replaceable units (CRUs) that require you to power off the server. For more
information about CRUs, see “Illustrated Parts Breakdown” on page 19 and “Customer-
Replaceable Units” on page 21.
Caution - These procedures require that you handle components that are sensitive
to electrostatic discharge. This sensitivity can cause the component to fail. To avoid
damage, ensure that you follow antistatic practices as described in “Take Antistatic
Measures” on page 61.
Caution - Ensure that all power is removed from the server before removing or installing
PCIe cards. You must disconnect all power cables from the system before performing these
procedures.
This section covers the following procedures:
■
“Remove an M.2 Mezzanine” on page 127
■
“Install an M.2 Mezzanine” on page 129
■
“Remove an M.2 Flash SSD” on page 130
■
“Install an M.2 Flash SSD” on page 131
Related Information
■
“Servicing Storage Drives (CRU)” on page 65
Remove an M.2 Mezzanine
1.
Remove the PCIe riser from the server.
See “Remove the PCIe Riser From PCIe Slots 3 and 4” on page 116.
Servicing the Internal M.2 Flash SSDs (CRU) 127

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
