Oracle X7-2 Service Manual

Install the Internal HBA Cables
b.
Press the SAS cable connector latch and then pull out the connector [3].
c.
Grasp the super capacitor cable connector and pull it out [3].
4.
Disconnect the super capacitor cable from the super capacitor [4].
Note - You might need to disconnect the data cable from the disk backplane to ease access to
the super capacitor.
5.
Carefully remove the SAS cables and the super capacitor cable from the server.
Related Information
■
“Remove the Internal HBA Card and HBA Super Capacitor” on page 170
■
“Install the Internal HBA Cables” on page 182
Install the Internal HBA Cables
1.
Carefully guide SAS cables and the super capacitor cable along the left-side
cable trough.
2.
Connect the super capacitor cable to the super capacitor [4].
For reference, use the illustration provided in “Remove the Internal HBA
Cables” on page 179.
Note -SAS cable assembly, part number 7117386 is required to connect the internal HBA card
to the disk backplane.
Note - If you disconnected the data cable from the disk backplane during the removal
procedure, reconnect the data cable.
3.
Connect the SAS cables and the super capacitor cable to the internal HBA card
[3].
When attaching SAS cables, ensure that you match the numbers on the SAS cables with
the SAS connectors on the disk backplane. Use the following table to ensure proper SAS
connections between the disk backplane and the internal HBA card.
182 Oracle Server X7-2 Service Manual • October 2017

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
