Oracle X7-2 Service Manual

Monitoring System Components
Component Name (Oracle ILOM CLI
Targets)
IPMI Type Description Values (if applicable)
/SYS/MB/P[0-x] FRU Host CPU FRU
/SYS/MB/P[0-x]/PRSNT Discrete sensor Host CPU is present. 01h-ENTITY_PRESENT
02h-ENTITY_ABSENT
/SYS/MB/P[0-x]/SERVICE Indicator Host CPU Fault-Service
Required LED
Color: Amber
Location: Motherboard
Off: Normal
On: Processor was diagnosed as faulty.
Related Information
■
“System Chassis Components” on page 285
■
“Cooling Unit Components” on page 287
■
“Disk Backplane Components” on page 287
■
“Memory Device Components” on page 289
■
“Power Unit Components” on page 289
■
“System Motherboard Components” on page 291
■
“System Firmware Components” on page 293
■
“Hard Disk Drive Components” on page 293
System Motherboard Components
The following table lists the system motherboard components.
Component Name (Oracle ILOM CLI
Targets)
IPMI Type Description Values (if applicable)
/SYS/MB FRU General host system motherboard
FRU
/SYS/MB/CPLD FRU Motherboard CPLD/FPGA firmware
version
/SYS/MB/NET[0-x] FRU Host Ethernet FRU
/SYS/MB/RISER[1-x]/PCIE[1-x] FRU PCIe slot
/SYS/MB/RISER[1-x]/PCIE[1-x]/PRSNT Discrete sensor PCIe slot is occupied 01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
Monitoring Components and Identifying SNMP Messages 291

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
