Install a Processor
Install a Processor
Caution - Be careful not to touch the processor socket pins. The processor socket pins are very
fragile. A light touch can bend the processor socket pins beyond repair.
1.
Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See “Take Antistatic Measures” on page 61.
2.
Ensure that the replacement processor is identical to the failed processor that
you removed.
For a description of the processors that are supported by the server, see “Product
Description” on page 15.
3.
Prepare the new processor for installation.
a.
Use the syringe (supplied with the new or replacement processor) to apply
approximately 0.3 cc of thermal grease to the center of the underside of the
heatsink [1].
b.
Distribute the thermal grease over the square heatsink-to-processor contact
area using a flat-edged tool [2].
Note - Ensure that you spread thermal grease evenly on the contact areas.
4.
Install the new processor.
