Monitoring System Components
Guide for Configuration and Maintenance Firmware Release 4.0.x in the Oracle Integrated
Lights Out Manager (ILOM) 4.0 Documentation Library at http://www.oracle.com/goto/
ilom/docs.
Monitoring System Components
The tables in this section identify the system components and describe the naming conventions
applied to the components of Oracle Server X7-2.
Each section corresponds to an IPMI entity ID and lists sensors, indicators, and field-
replaceable units (FRUs) related to that entity. The tables contain the following fields:
■
Component Name – Shows the user-visible component name used in management
interfaces to refer to a specific sensor, indicator, or FRU. The IPMI name is a shortened
form of the component name, and is indicated by the boldface portion of the component
name.
■
IPMI Type – Indicates the type of sensor, indicator, or FRU represented.
■
Description – Describes the particular component name reference.
■
Values – Defines the states of the sensor, indicator, or FRU entity, and any specific units or
values that are expected, if applicable.
Note - Some component names are hidden in the Oracle ILOM user interfaces. Further, as of
Oracle ILOM 3.2, the Oracle ILOM 3.0 legacy targets /SYS and /STORAGE have been replaced
by /System. Even though these legacy targets might be hidden, you can still use them to issue
commands. For information on legacy targets, see the ILOM 3.2 Documentation Library at
http://www.oracle.com/goto/ilom/docs.
This section includes information for the following server components:
■
“System Chassis Components” on page 285
■
“Cooling Unit Components” on page 287
■
“Disk Backplane Components” on page 287
■
“Memory Device Components” on page 289
■
“Power Unit Components” on page 289
■
“Processor Components” on page 290
■
“System Motherboard Components” on page 291
■
“System Firmware Components” on page 293
284 Oracle Server X7-2 Service Manual • October 2017
