Oracle X7-2 Service Manual

Populating DIMMs for Optimal System Performance
■
Within a memory channel, DIMMs must be populated in the black sockets first, and then in
the white sockets.
■
If you are installing a mix of RDIMM sizes (for example, 16-GB and 32-GB), install the
larger size RDIMMs first, then the smaller RDIMMs, until all of the RDIMMs are installed.
■
The server operates properly with a minimum of one DIMM installed per processor.
Populating DIMMs for Optimal System Performance
Optimal performance is generally achieved by populating the DIMMs so that the memory is
symmetrical, or balanced. Symmetry is achieved by adhering to the following guidelines:
■
In single-processor systems, populate DIMMs of the same size in multiples of six.
■
In dual-processor systems, populate DIMMs of the same size in multiples of twelve.
■
Populate the DIMM sockets in the order described in the following sections.
The following sections provide an example of how to populate the DIMM sockets to achieve
optimal system performance.
Note - Not all possible configurations are shown here.
■
“Populating DIMMs in Single-Processor Systems for Optimal System
Performance” on page 100
■
“Populating DIMMs in Dual-Processor Systems for Optimal System
Performance” on page 102
Populating DIMMs in Single-Processor Systems for Optimal
System Performance
In single-processor systems, install DIMMs only into DIMM sockets associated with processor
0 (P0). Starting with socket P0 D7, first fill the black sockets, and then fill the white sockets, as
shown in the following figure.
100 Oracle Server X7-2 Service Manual • October 2017

Oracle X7-2 Specifications

General

Processor	Intel Xeon Scalable processors
Number of Processors	1 or 2
Memory	Up to 1.5 TB DDR4
Memory Slots	24 DIMM slots
Form Factor	2U Rackmount
Storage Bays	8 x 2.5-inch
CPU Socket	Socket P (LGA 3647)
Power Supply	Redundant hot-swappable power supplies
